PM stepping motor

Model No.:
CB-325BY24L01
Features:
PM stepping motor



Product Features


1) PM stepping Motor.



Product Description


1)Type:PM stepping Motor
2)Stepping angle:15°
3)No. of phase:4

4)Resistance:20Ω

5)Inductance:14.75mH

6)voltage:9V

7)No-load starting frenquency(pps):600
8)pull-in torque:20g.cm
9)Detent torque:60g.cm

10)Holding torque:135N


Note: These are only the typical technical data for reference, other specification such as voltage, speed, torque, shaft length can be customized.

Product Information

Dimension of motor:42.3*42.3*Length  mm
Length of motor:23mm
Color: black & silver



Quotation Information


Price Range:$20- $60 per piece
Minimum Order Quantity:100 pieces
Lead time:30 days
