Outer Rotor brushless DC motor

Model No.:
CB90BLW
Features:
Outer Rotor brushless DC motor



Product Features


1) Outer rotor DC motor.
2) Brushless DC motor.



Product Description


1)Motor specification:

Model
CB90BLW33-24V-850A
CB90BLW55-48V-5100A
Number of poles
22
22
Number of phase
3
3
Rated voltage   VDC
24V
48V
Rated speed     RPM
800
500
Rated torque    N.m
0.6
2.0
Rated power   W
50
100
Peak current   A
9.5
8.5
Line to line resistance  ohms@20
1.1
2.1
Line to line inductance   mH
1.4
5.0

Note: These are only the typical technical data for reference, other specification such as voltage, speed, torque, shaft length can be customized.



Product Information

Diameter of motor:90mm
Length of motor:33mm
Color: siliver



Quotation Information


Price Range:$32 - $58per piece
Minimum Order Quantity:200 pieces
Lead time:30 days
