Contents

Separated closed-loop stepping servo motor

Model No.:
SC42-03
Features:
closed-loop stepping servo motor



Product Features


1) Separated closed-loop stepping servo motor.
2) Stable running.

3) Long service life.



Product Description


1)Motor specification:

TypeSC42-03SC42-06
Phase current(A)2.32.3
holding torque(N.m)0.30.6
speed(rpm)18001800
length(mm)6176
weight(kg)0.30.5

Note: These are only the typical technical data for reference, other specification such as voltage, speed, torque, shaft length can be customized.



Product Information

Diameter:42m
Length of motor:61 or 76mm
Color: siliver/black



Quotation Information


Price Range:$60 - $150per piece
Minimum Order Quantity:100 pieces
Lead time:30 days
