Product Features

1) Robust design makes it more durable

2) Waterproof level:IP54, suitable for outside application.

3) ROHS material

4) Suitable for Pump

Product Description

1) Rated voltage:24v

2) No-load speed:2200r/min

3) No-laod current:3.0A

4) Rated torque:1.5N.m
5) Rated speed:2000+/-8%

6) Rated current:17A

7) Static resistance:>/=50MΩ

8) Voltage tolerace:500AC/1S/5mA

9) Working mechanism: S3 model    10-15 min

10) Diameter:114.3mm   Length:174mm

12) Shaft diameter:15.9    Shaft length:52.5    Step diameter:114.3      Screw:M10      Slot width:4.8

Product Information

Length: 174mm

Weight: 5.6kg

Color: black

Quotation Information

Price Range: $ 57.58- $98 per piece

Minimum Order Quantity: 200 pieces

Lead Time: 30 days
